IBMH100
Embedded PC

Modular Industrial PC for professional use Industrial computer in sturdy steel sheet / aluminium housing 1 x expansion slot 1 x drive bays tool-less accessible System components are accessible behind service-friendly covers Wireless fail-safe construction (plugged and screwed components only) Designed for industrial applications in continuous operation Easy installation with mounting bars or VESA mounting interface Long-term availability

01-Industrie-Embedded-PC-IBMH100 / TL Produkt-Welten / Industrie-PC / Embedded-PC
01-Industrie-Embedded-PC-IBMH100 / TL Produkt-Welten / Industrie-PC / Embedded-PC
Order number: 15100538
gross price: €0.00
Price on request

Prices plus VAT plus shipping costs

Delivery time: upon request

HIGHLIGHTS
  • EmbeddedLine Kompakt Industrie PC
  • 1 x Erweiterungssteckplatz
  • 1 x Laufwerksschacht werkzeuglos von vorne zugänglich
  • Langzeitverfügbarkeit
Download PDF datasheet

SPEZIFIKATIONEN
Order number: 15100538
Manufacturer: WM
Matchcode manufacturer: nein
Manufacturer: Winmate
series name: EmbeddedLine
Manufacturer item number: IBMH100
mechanics: Embedded-PC
dimensions width: 27,6
dimensions height: 20,7
dimensions depth: 4,52
Material housing: Aluminium / aluminium
protection front: IP20
protection device: IP20
colour: RAL 9005 Tiefschwarz / Jet black
controls: 2 Keys: Power, Reset, Status-LEDs
VESA-Mounting Interface: VESA 100 x 100 mm
wall mounting: Ja / yes
cooling: lüfterlos / fanless
chipset: Intel System on chip
CPU Typ : Atom
CPU Model : E3845
CPU 64bit : Ja
CPU speed: 1,91 GHz
CPU cores: 4
CPU socket: FCBGA1170
RAM size (MB): 4096
RAM max. size (MB): 8192
RAM Number of benches: 2
RAM Typ : SO-DDR3L
RAM speed: 1600
Grafik Controller: Intel HD Graphics Z3700 series
Ethernet Controller: 2 x Intel Ethernet Controller
Mini-PCIe-slot: 1
SSD design: mSATA
SSD max. number: 1
SSD capacity (GB): 128
Display : 1x HDMI (optional), 1x VGA (optional)
USB : 4 x USB 2.0
LAN : 2x RJ45 - 10/100/1000 Mbps
serial: 1 x RS-232
controls: Power On/Off, Kontroll-LEDs
voltage input DC: 12-24 V/DC
power adapter: 100 - 240 V/AC, 4-pin, extern
WLAN: Optional / optional
operating-system support: Optional / optional
operating temperatur min.: 0°C
operating temperatur min.: 50°C
warranty: 24 Monate / 24 months
