G101G7
Robotics Controller
10.1" Rugged Ground Control Station ARM A78 + A55 Processor All-weather, dust and waterproof IP65 design Shock, vibration and drop resistance (MIL-STD-810H) Low-latency video SW decoder for high-resolution real-time video playback Supports WIFI, BT and optional 4G/5G Embedded TPM IC and optional OPAL SSD
05-Rugged-Robotic-Controller-G101G7.jpg / TL Produkt-Welten / Rugged Robotic Controller / Robotics Controller
04-Rugged-Robotic-Controller-G101G7.jpg / TL Produkt-Welten / Rugged Robotic Controller / Robotics Controller
02-Rugged-Robotic-Controller-G101G7.png / TL Produkt-Welten / Rugged Robotic Controller / Robotics Controller
Order number:
25100095
gross price: €0.00
Price on request
gross price: €0.00
Prices plus VAT plus shipping costs
Delivery time: upon request
SPEZIFIKATIONEN
| Order number: | 25100095 |
| Manufacturer: | WM |
| Matchcode manufacturer: | nein |
| Manufacturer: | Winmate |
| series name: | Rugged Robotic Controller |
| Manufacturer item number: | G101G7 |
| mechanics: | Rugged Robotic Controller |
| dimensions width: | 36,93 |
| dimensions height: | 22,15 |
| dimensions depth: | 6,73 |
| weight: | 2,4 |
| protection device: | IP65 |
| colour: | Schwarz / black |
| cooling: | aktiv / fan cooling |
| Display-diagonal (inch): | 10,1 |
| aspect ratio: | 16:10 |
| resolution: | 1920 x 1200 |
| brightness: | 800 cd/m² |
| contrast: | 800:1 |
| Display-Technology: | LCD, LED Backlight |
| Touch-Screen : | Projected Capactive / Multi-Touch |
| usability: | Finger/ Handschuh/ finger/ glove |
| CPU Typ: | ARM Genio 510 |
| CPU Model: | A78 + A55 |
| CPU speed: | 2,2 GHz + 2,0 GHz |
| RAM size (MB): | 4096 |
| SSD design: | eMMC |
| SSD capacity: | 64 |
| safety: | TPM 2.0 |
| WLAN: | Ja / yes |
| Bluetooth: | Ja / yes |
| WWAN: | Optional / optional |
| Camera front: | Ja / yes |
| Camera front resolution: | 2MP |
| Video: | 2x Mirco HDMI |
| USB: | 1x USB 2.0 |
| LAN: | 1x M8 LAN (10/100 Mbps, Max 250 Mbps) |
| Card Slot: | 1x Micro SD Slot |
| Audio: | 1 x Speaker |
| Power: | 1x 19 V/DC, DC plug |
| Docking connector: | 1x 19-pin Docking Connector |
| operating system: | Android 13.0 / Linux Ubuntu |
| operating temperatur min.: | -20°C |
| operating temperatur max.: | 60°C |
| Shock: | MIL-STD-810H Method 516.8 Procedure I |
| Vibration: | MIL-STD-810H Method 514.8 Procedure I |
| voltage input DC: | 19 V/DC |
| external power supply: | 19 V/DC, 100 - 240 V/AC, DC plug |
| battery: | 11.4V, 3500 mAh Battery (3S1P) |
