Industrial edge AI computing with high-performance box IPC

Industry 4.0 is becoming increasingly important and with it future-oriented applications such as edge AI, deep learning and visual recognition systems. We are meeting the increased demand for high computing power, strong connectivity and large amounts of data with this new box IPC for edge AI computing.

All components are designed for maximum performance: The 12th generation Core i7 CPU, high-speed DDR5 memory, extensive network connections and interfaces as well as the graphics option of an NVIDIA RTX GPU leave nothing to be desired.

CPU performance comparison


Powerhouse: Intel® Core™ i7-12700TE processor of the 12th generation (“Alder Lake”) with 12 cores and 1.0 to 4.6 GHz depending on the operating mode, 25 MB Intel® Smart Cache and Intel® UHD Graphics 770. The CPU from the Intel Embedded Program for long-term available CPUs offers you ample performance reserves for the execution of advanced AI algorithms and models.

The robust sheet steel construction with an appropriate active cooling concept ensures reliability, component protection and fail-safety even in 24/7 continuous operation.

Conclusion: The AI Edge Computer WNAI-E800 offers a wide range of possible applications in various industrial sectors. Its ability to analyze large amounts of data in real time and integrate machine learning makes it an indispensable component for modern industrial applications. Companies that rely on this technology benefit from improved efficiency, reduced downtime and higher product quality.

Discover WNAI-E800 Box-IPC
All connections, interfaces and operating elements are integrated in the front of the Box PC

Front view in maximum version with all options: Four additional Ethernet ports, four extra USB ports, two serial interfaces, HDMI and an NVIDIA graphics card.

NVIDIA graphics card in the box PC

Optional NVIDIA RTX A4000/A5000/A6000 GPUs expand your capabilities for AI-powered operations, video applications and deep learning.


Cloud integration of the industrial PC

Use cloud integration for seamless scalability of AI applications, collaborative learning and data sharing with other cloud-connected systems.

The box IPC is actively ventilated.

Effective temperature management is essential for a controlled operating temperature in continuous operation. This enables us to achieve improved longevity and minimize the risk of component failure.


The front offers plenty of space for interfaces.

Edge AI computing requires efficient connection and processing of data from various sensors. We can flexibly adapt the Box-IPC to different industry requirements for you.





Specifications Box Industrial PC WNAI-E800
CPU:  Intel Core i7-12700TE (12 × 1,4 GHz)
Chipset:  Intel R680E
OS Support:  Windows 10/11 IoT Enterprise
Memory:  16 GB DDR5 (max. 64 GB)
Storage:  512 GB M.2-SSD (max. 2 TB)
Interfaces:  2 × RJ45 Ethernet,
4 × USB 3.2 (Type A),
1 × DisplayPort 1.4,
3,5 mm Audio I/O
Options:  4 × RJ45 Ethernet extra,
4 × USB 2.0 (Type A),
1 × HDMI 2.0,
1 × RS232/422/485,
1 × RS232
Expansions:  1 × PCIe 5.0 (x16)
Graphics option:  NVIDIA RTX A4000/A5000/A6000 GPU
Security:  TPM 2.0
Operating temp.:  -20 ~ 50 °C
Material:  Steel sheet
Dimensions:  22 × 16 × 36 cm (W×H×D)
Mounting:  Desk/wall mount
