L156AD-4KM1
Industrial Automation, Rugged Industrial Laptop

Rugged Laptop for professional use Shock, vibration and drop protected (MIL-STD-810H) Multi-touch (PCAP) Wide range of options and accessories for data capture, communication, docking, mounting, power, peripherals and transportation The ideal partner for warehouse, logistics, automotive, outdoor, smart factory, field service etc. Long-term availability

01-L156AD-4KM1.jpg / TL Produkt-Welten / Mobile Computing / Rugged Laptop
01-L156AD-4KM1.jpg / TL Produkt-Welten / Mobile Computing / Rugged Laptop
02-L156AD-4KM1.jpg / TL Produkt-Welten / Mobile Computing / Rugged Laptop
02-L156AD-4KM1.jpg / TL Produkt-Welten / Mobile Computing / Rugged Laptop
03-L156AD-4KM1.jpg / TL Produkt-Welten / Mobile Computing / Rugged Laptop
03-L156AD-4KM1.jpg / TL Produkt-Welten / Mobile Computing / Rugged Laptop

Order number: 25150002
gross price: €0.00
Price on request

Prices plus VAT plus shipping costs

Delivery time: upon request

HIGHLIGHTS
  • Widerstandsfähige Bauform
  • Schlankes Design
  • IP65 wasser- und staubdicht
  • Schock-, Vibrations- und Sturz-Resistenz gemäß MIL-STD-810H
Download PDF datasheet

SPEZIFIKATIONEN
Order number: 25150002
Manufacturer: WM
Matchcode manufacturer: nein
Manufacturer: Winmate
series name: Rugged Laptop
Manufacturer item number: L156AD-4KM1
mechanics: Rugged Laptop
dimensions width: 38,76
dimensions height: 3,88
dimensions depth: 25,6
weight: 3,8
protection device: IP65
colour: Schwarz / black
cooling: aktiv / fan cooling
Display-diagonal (inch): 15,6
resolution: 3840 x 2160
brightness: 400 cd/m²
contrast: 800:1
Display-Technology: LCD, LED Backlight
Touch-Screen : Projected Capactive / Multi-Touch
CPU Typ: Core i7
CPU Model: 12700H
CPU speed: 2,30 GHz
CPU cores: 14
RAM size (MB): 16384
RAM max. Größe (MB: 65536
RAM Typ: SDRAM-DDR5
SSD design: M.2
SSD capacity: 256
SSD number: 1
safety: TPM 2.0
WLAN: Optional / optional
Bluetooth: Optional / optional
WWAN: Optional / optional
Ethernet_connections: 2x RJ-45
Ethernet data transfer: 2 x Gigabit-LAN
Camera front: Ja / yes
Camera front resolution: 2MP
RFID: Optional / optional
Finger Print: Optional / optional
Video: 1x HDMI 4K (optional)
USB: 3x USB 3.0 (Type A), 1x USB 3.0 (Type C)
serial: 1x RS-232/RS-422/RS-485 (DB9)
LAN: 2x RJ45 - 10/100/1000 Mbps
Card Slot: 1x Micro SDXC Slot, 1x Nano SIM Slot
Audio: 1x Audio Combo jack 3.5mm
Power: 1x 19 V/DC, DC plug
controls: 5 Keys: Power, 4x Function Key
operating system: Windows 10 IoT Enterprise
operating temperatur min.: -20°C
operating temperatur max.: 60°C
Shock: MIL-STD-810H Method 516.8 Procedure I
Vibration: MIL-STD-810H Method 514.8 Procedure I
Drop: MIL-STD-810H Method 516.8, 3 ft
voltage input DC: 19 V/DC
external power supply: 19 V/DC, 100 - 240 V/AC, DC plug
battery: 2x 11.55V, 3220mAh Li-Ion Battery (3S1P)
battery Hot-Swap: Ja / yes
